Type | Snap lock/Threaded |
Shell material | Brass with chrome plated |
Insert material | PBT , max temperature 180℃ |
Contact material | Brass plated with gold |
Wire connection method | Solder |
Mating cycle | 500 |
temperature range | -30℃~+85℃ |
Protective Structure | IP67(IEC60529) |
Panel hole cutout diameter | 12mm |
Number of crimp contact | 2~9pin |
